Electric or semi-automatic mini cranes with capacity up to 450 kg.

The JT450_TR (with rotation) is the electric mini crane of the «JT-line cranes» range.
The new JT -LINE series is the perfect solution of mini-crane that, with a limited investment, lets to carry our any type of lifting (industrial maintenance, tooling of CNC or automatic machines, mould lifting, activities on construction sites, etc.) with the maximum safety and flexibility.

  • 12 months warranty on all components
  • Counter balanced shop crane
  • Tested 25% overload before delivery
  • With double action hydraulic pump, fast and easy / Allows to work close to a machine
  • Unique operate handle, brake design, mobile and foldable
Additional information
FeaturesJT450_TR (with rotation)
Maximum load capacity450 Kg
Standard min. hook’s height from the ground2.840 mm
Standard max. hook’s height from the ground2.005 mm
Capacity at standard max. telescopic extension120 Kg
DriveElectric
LiftingElectric
TelescopicingElectric
Rotation 270°Electric
Dimensions- lenght1.310 mm
Dimensions- width1.010 mm
Dimensions- height1.845 mm
Adjustable speed from / toFrom 0 to 40 m/min
Max. surmountable slope ( unloaded )5%
Max. surmountable slope ( loaded )3%
Front wheels2 x Ø 200 mm
Rear driving wheelx Ø 250 mm + 2 x Ø 60 mm
Wheels materialPolyurethane
Total weight:1.200 kg
Electric motor power2,2 KW / 24 V + 0,7 KW / 24 V
Hardened battery (standard)80Ah / 12 V
Battery charger on board110 / 240 V -50/60 Hz
Gel battery●
Proportional control on board of all mouvements●
Certification to standard 2006/42 CE●
Drive hydraulic unit●
Automatic braking system●
Overloading safety system●
Pressure safety valves on each movements●
Safety emergency electric devices●
Winch (lifting capacity on demand)●
Possibility to do all movements with max. Load●
