Tow Tractor 730 T/TB/TK ac
Pallet truck – Tow Tractor walk behind
The 730 T are walk behind electric tow tractors designed as standard for towing trailers of up to 5.0 t and lifting loads of up to 3.0 t. These tractors can be used with different types of trailers. The operator can unlock the hook without releasing the tiller, minimising therefore the handling times.
For towing trailers of up to 5.0 t and lifting loads of up to 3.0 t
Additional information
| Operator | operator accompanied |
|---|---|
| Towing capacity | 5.0 t |
| Lifting capacity | 3.0 t. |
Frame
Made of bent sheet metal to minimise any tensions induced by welds, ensuring maximum durability and best mechanical resistance under any conditions. The battery compartment can be easily opened by lifting the cover, simplifying the daily and periodical battery recharge and check operations. Particular attention has been paid to provide easy access to wear parts, minimising therefore the routine maintenance costs. The tow hook is made of high strength special steel to minimise wear-out. Resistant powder coating.
Electronic system
730T is equipped with highly efficient and reliable DC electronic devices. The controls are equipped with anti roll-back devices which control and check all machine functions and allow unlimited adjustments for performance optimisation, adapting the truck to the operation to be carried out. All electric drive and braking parameters can be set electronically from a control panel, according to customer’s requirements. All models are equipped with timer and battery level indicator with auto-lock function that switches on once 80% of the battery capacity is discharged.
Drive
Powerful and reliable DC traction motors, able to satisfy even the most demanding requests for performance, providing the necessary amount of power every time, as the speed of the truck can be adjusted by changing the position of the throttle.
Braking
There are three braking systems in this range:
- braking by reversing the running direction and releasing the throttle (service braking that can be adjusted from the control panel)
- emergency braking that takes place automatically if the tiller is suddenly released or lowered (electromagnetic brake)
- parking brake.
Tiller
Result of a meticulous ergonomic study that combines operating comfort with modern industrial design. The tiller is fitted with easy to reach controls, ensuring enhanced productivity, precision and efficiency. When released, the tiller returns smoothly to its vertical position thanks to the gas spring fitted with slowdown limit switch.
- steering head, manufactured in ABS, with a steel core capable of absorbing strong knocks without deforming
- fork lifting and descent buttons on both sides
- acoustic warning button are in a central position
- safety guaranteed by excellent positioning of the crush-prevention device.
